Key Technical Specifications

• Model: iOM10.2B4.2AD
• Cleaning Technology: iO Magnetic Micro-vibrations with Oscillating-Rotating action.
• Artificial Intelligence: 3D Teeth Tracking and AI recognition to monitor brushing across front, top, and back surfaces.
• Smart Modes (7): Daily Clean, Sensitive, Super Sensitive, Intense, Gum Care, Whitening, and Tongue Cleaner.
• Interactive Display: Full-color display for real-time encouragement, mode selection, and brush head replacement alerts.
• Charging: Magnetic iO Sense™ Charger provides a full charge in just 3 hours.
• Pressure Sensor: Smart Pressure Sensor lights up red when brushing too hard, white when too light, and green when just right.

• REVOLUTIONARY iO TECHNOLOGY – Combines Oral-B’s iconic round brush head with gentle micro-vibrations for effective cleaning.
• SMART PRESSURE CONTROL – Alerts you when the pressure is too high or too low, with a 2-minute timer for optimal brushing.
• INTERACTIVE COLOR DISPLAY – Personalize your brushing experience by choosing your favorite light color in the Oral-B app.
• 3D TEETH TRACKING – Utilizes A.I. and position detection (16 zones) to recognize your brushing style and ensure the best results daily. Bluetooth connected App offers personalized live-coaching.
• INTUITIVE GUIDING LIGHTS – Provides real-time feedback on pressure and coverage, ensuring you never miss a zone.
• MAGNETIC CHARGER – Fast charging in approximately 3 hours for added convenience.

 Advanced Core Technologies

iO™ Magnetic Drive System

Unlike traditional mechanical motors, the iO system uses a frictionless magnetic drive that transfers energy directly to the tips of the bristles. This creates micro-vibrations ($250 \text{Hz}$) that work in tandem with the oscillating-rotating head to break up plaque more effectively than standard sonic brushes.

iO Sense™ Smart Charger

The iO 10 is the only model featuring the iO Sense™ hub. This base acts as a secondary “brain” that provides:

• Live Coverage Mapping: Six LED segments on the base represent different zones in your mouth, turning from blue to white once a zone is fully cleaned.
• Brushing Timer: A digital clock display helps you maintain the dentist-recommended $2$ minutes.
• Optimal Pressure Feedback: Visual cues on the base mirror the handle’s pressure sensor.

AI & 3D Teeth Tracking

The handle contains an inertial measurement unit (IMU) with an accelerometer and gyroscope. Combined with AI algorithms, it tracks the brush’s orientation in 3D space across 16 surfaces (buccal, lingual, and occlusal surfaces of the upper and lower teeth).

The 7 Smart Brushing Modes

Each mode utilizes a specific frequency of micro-vibrations and oscillation speeds:

1. Daily Clean: The standard mode for high-frequency plaque removal.
2. Sensitive: Lower intensity for a gentle yet thorough clean.
3. Super Sensitive: Minimal vibration for highly inflamed gums or post-surgical care.
4. Intense: Maximum power for a “dentist-clean” feel; ideal for heavy plaque build-up.
5. Whiten: Varied speeds to polish away surface stains.
6. Gum Care: Gentle massage of the gingival margin to improve tissue health.
7. Tongue Clean: Specialized cycle for the tongue surface to eliminate breath-causing bacteria.

Physical & Digital Interface

Interactive Color Display

The OLED screen provides:

• Greeting: Personalized “Hello” and “Good Morning.”
• Visual Timer: Counts up to $2:00$ with a celebratory icon upon completion.
• Battery Status: Precise percentage-based tracking.
• Replacement Alert: A yellow light indicates the brush head has reached the $3$-month usage limit.

Smart Pressure Sensor

• White: Under-brushing (not enough pressure).
• Green: Optimal pressure (the “Sweet Spot” for maximum efficacy).
• Red: Excessive pressure (the motor automatically slows down to protect enamel).

Power & Connectivity

• Battery Chemistry: High-density Lithium-Ion.
• Fast Charge: $0\%$ to $100\%$ in $\approx 180$ minutes via the magnetic induction base.
• Bluetooth 5.0: Synchronizes brushing data to the Oral-B App (iOS/Android) for long-term health trends and habit coaching.
• Voltage: Universal voltage ($100$–$240\text{V}$), making it travel-friendly.

Box Contents (iOM10.2B4.2AD)

• 1 iO Series 10 Handle (Cosmic Black)
• 1 iO Sense™ Smart Charger
• 1 Power2Go Charging Travel Case (Charges the brush inside the case)
• 1 iO Ultimate Clean Replacement Head
• 1 Mini Head Holder

Pro Maintenance Tips

• Rinse Routine: After every use, remove the brush head and rinse the metal pin and the inside of the head to prevent dried paste build-up.
• Firmware Updates: Use the Oral-B app to update the handle’s firmware, which often improves AI tracking accuracy.

Product FAQ

Q: What makes the Series 10 different from the Series 9? A: The Series 10 introduces the iO Sense™ Smart Charger, which provides live coaching directly on the charging base, showing you where to brush and how much pressure to apply without needing to look at your phone.

Q: How long does the battery last on a full charge? A: On a full 3-hour fast charge, the battery typically lasts for over two weeks of twice-daily brushing ($2$ minutes per session).

Q: Is the iO Series 10 compatible with older Oral-B brush heads? A: No, the iO Series uses a specific iO Specialized Brush Head designed to work with the magnetic drive system. Standard CrossAction or FlossAction heads will not fit.

Q: Can I use the brush in the shower? A: Yes, the handle is waterproof; however, the magnetic charging base and the iO Sense™ unit should be kept on a dry surface away from direct water contact.

Q: What is 3D Teeth Tracking? A: It is an AI-powered feature that maps the 16 zones of your mouth in 3D through the Oral-B App, ensuring you reach $100\%$ coverage across all tooth surfaces.
