Product Features
- 802.11ax
- Dual-band AX5400
- 2×4 Spatial streams
- Linksys Intelligent Mesh™
- WiFi security
- Guest WiFi
- Speed Check
- Parental Controls
- Band steering
- Beamforming
- Dynamic Frequency Selection (DFS) support
- Next-gen orthogonal frequency-division multiple access (OFDMA) support
- Coverage of up to 2,700 sq ft per node
- Bluetooth® 5.1 Low Energy
- TR069 support
- Indicator light
- Automatic setup / Auto Configuration Server (ACS) support
Hardware
- Dimensions: 3.385 x 3.385 x 7.3 in
- Weight: 0.50 kg (1.1 lb)
- Five internal antennas
- Ports/Buttons/Switch:
- Three ethernet ports (1 Gbps each)
- One internet port (2.5 Gbps)
- Power port (12V, 2A)
- Reset button
- Wi-Fi Protected Setup™ (WPS) button
- Power switch (sliding switch)
Product Requirements
- An active du internet connection
- A Linksys cloud account for remote access
- A mobile device with the latest version of the Linksys app for remote access (optional)
Package Contents
- One Linksys SPNMX56
- One ethernet cable (CAT5e)
- One power adapter with an interchangeable plug
- Quick start guide
- Legal insert
Setting up the Linksys SPNMX56DU
This router comes with ACS which is an automatic setup feature. The initial installation will be provided by du. If you need to reset the node and configure it again, simply restart the ACS process.
When using the automatic setup, the router will install itself as the parent router once it is connected to du’s equipment and detects an internet connection. Do not try to set up the node with the Linksys app while the node is going through the ACS setup, as the Linksys app will not detect the node.
Changing the WiFi Settings
1. Open the Linksys app.
2. Log in to the Linksys app dashboard.
3. Tap the menu icon.
4. Tap on Wi-Fi Settings.
5. Tap the field you want to change on the Wi-Fi Settings and then tap Save.
Resetting the Linksys SPNMX56DU
1. Press and hold the Reset button at the bottom of the device.
The light at the front of the router will flash bright red, pulse dimly three times, flash bright red again, and then turn OFF. You can release the reset button after this process. This should take about 15 to 20 seconds.
2. Wait for the light to turn solid purple, indicating it is ready to be set up.
